ITEM NO. CONTENTS
M-02-RF-205S
22" Drilling Machine Machine Weight:

8 speed gearbox with big speed range 75-3140rpm 220 kgs/ 230 kgs(NW/GW)

MT-3 spindle taper with tool quick eject system

150mm long spindle travel

Main Motor: 1.5 (3-Phase) HP

Speed: 2 Speed Motor (standard):

60HZ 90~3580 rpm; 50HZ 75~3140 rpm

Drilling Capacity: 32mm

Taper: MT3; Stroke: 150mm; Depth: 284mm

Table Size: 505*405mm

Column Diameter: Ø 100mm

Spindle Nose To Table: 915mm

Spindle Nose To Base: 1262mm

Quill Diameter: Ø 62mm

No. of Slot: 2; T Slot Size: 16*26 mm

ITEM NO. CONTENTS
M-02-RF-225CS
Circular Coldsaw
Main Power: 1 HP
Oil Bath Reduction Gear Box: 27:1 mm
Max Blade Size: 225 mm
Blade Revolution Speed: 52 rpm
Vice Opening: 80mm
Weight of the Machine w/o Stand: 60kgs
Weight of the Machine w/ Stand: 80kgs

ITEM NO. CONTENTS
M-02-RF-25
Bench Type Milling Drilling Machine
Main Motor: 3/4 (HP)
Speed : 1 Speed Motor (standard):
60HZ / 110-2580 rpm (12 speeds)
50HZ / 90-2150 rpm (12 speeds)
Taper: MT3 or R8
Stroke :95mm; Depth: 170mm
Table Size: 585 x 190mm
X Travel: 380mm; Y Travel: 150mm
Column Diameter: Ø 92mm
No. of T Slot: 4; T Slot Size: 14 x 24

ITEM NO. CONTENTS
M-02-RF-812
Light Duty Band Saw 5" x 6" Step Pulley
Main Motor: 3/4 (1 or 3-Phase)) (HP)
Speed : 60HZ / 27-41-59-78 (Mt/min)

50HZ / 22-34-49-64 (Mt/min)
60HZ / 90-135-197-255 (Ft/min)
50HZ / 70-110-160-210 (Ft/min)
Saw Blade: 20 x 0.8 x 2362 mm (WxTxL)

0.8 x 0.0315x93 inch (WxTxL)
Machine Dimensions: 1235 x 430 x 955 mm

48.65 x 17 x 37.6 inch
Weight: 150 / 185 kgs; 330 / 407 lbs(NW/GW)

ITEM NO. CONTENTS
M-02-WV-310R
Inverter Band Saw
Double miter cutting 60°(R), 45°(L)
Blade tension gauge and breakage
switch.Manual and quickly locking vise.
Motor: 1.5HP 50HZ
Blade Speed (50HZ): 36/72 MPM
Packing Size: 1676 x 749 x 1054 mm
(66” x 29.5” x 41.5”)
Weight: 360 kgs/ 410 kgs(NW/GW)

ITEM NO. CONTENTS Weight:
M-02-WL-800SA 5500 kg/5700kg(NW/GW)
Heavy Duty Band Saw
Single vise clamping.
Blade tilt detect sensor and readout (option).
Vise clamping pressure regulator (opting).
Laser position guide line.
Cutting: ●800mm █800mm x 800mm

Blade Size: 54 x 1.6 x 8300 mm
Blade Speed: 20~85 MPM
Blade Motor: 10 HP (7.5KW)
Hydraulic Motor: 3 HP (2.2KW)
Coolant Motor: 1/4 HP
Hydraulic Tank: 90L; Coolant Tank: 160L
Cutting Table: 620mm
Packing Size: 4300 x 1400 x 2400mm
